Standard Features
• Available in 3, 5, and 10 IDC models
• IDC or NAC pairs convertible to single Class A circuits (10 and
5 IDC panels only)
• CleanMe® provides remote annunciation if a detector drifts out
of UL/ULC limits reducing the chance of a false alarm
• Combination Waterflow and Supervisory IDCs reduces wire and
zone counts
• NACs programmable by zone and individually selectable for
Genesis, continuous, temporal outputs, or coded
• Front panel programmable simplifies installation and servicing
• Optional fully integrated DACT/Dialer for PC programming
• Genesis option allows precision synchronization and audible
silence over two wires without additional modules
• On-board relays for Alarm, Supervisory and Trouble
• Optional serial bus relay modules are programmable for common or zone activation
• Optional serial bus remote annunciator family
• One person walk-test (audible or silent)
• Expandable power supply on 10 IDC panel reduces booster
power costs
• Trim ring available for semi-flush mounting
• Supports “MC”, 7349, 400, 500 and 700 series detectors
